Leaf COB Light

Rayna Make Leaf COB Light | Made in India | up to 60 Months Warranty | Available in 7W, 12W, 18W, 30W and 50W | Colour: 3000K, 4000K, 5000K, 6000K

Leaf COB Downlight — technical dimensions

The Leaf is the slim member of our COB range. At every wattage its cut-out is smaller and its body shorter than the Caren, which makes it the choice when the ceiling is crowded with ducting or when a tighter grid of lights is wanted.

Watt	Lumens	Cut-out (mm)	OD (mm)	Height (mm)
7W	700 – 900 lm	52	60	45
12W	1200 – 1600 lm	60	70	52
18W	1800 – 2400 lm	72	80	64
30W	3000 – 4000 lm	127	132	78
50W	5000 – 6500 lm	145	150	84

Lumen output varies with CCT and beam angle.

Choosing a Leaf

Depth matters as much as diameter here. At 45mm tall the 7W fits ceilings where a deeper fixture will not go, and the 12W at 52mm is the usual pick for a false ceiling with limited space above it. The 18W covers living rooms and cabins, while the 30W and 50W are for high ceilings and showroom floors.

If the ceiling is already cut and you are replacing an older fixture, send us the existing cut-out diameter and we will tell you which Leaf drops straight in.

Finishes

Black, White, Gold, Rose Gold and Gun Metal. Beam angles of 15°, 28°, 38° and 60° are available, so the same fixture works for wall washing and for general light.

Every Leaf is available in Economy and Premium build, and in a Smart (WiFi / app-controlled) version. Made in India at our own facility.
